Sports Event Modular Container House
The house uses a galvanized steel frame with high-strength bolted connections, providing good structural stability, corrosion resistance, and long-term durability. Different frame thicknesses are available to meet various project budgets and strength requirements.
Better Insulation and Indoor Comfort
The wall system can use EPS, rock wool, or PU sandwich panels. EPS panels offer good thermal insulation and cost efficiency, rock wool panels provide better fire resistance and sound insulation, while PU panels deliver stronger heat preservation performance for hot or cold climates.
Fast Installation and Flexible Use
Factory-prefabricated components reduce on-site construction work and allow quick assembly. Units can be used independently, connected horizontally, or stacked to create dormitories, offices, classrooms, clinics, emergency housing, and other modular buildings.
| Item | Standard Specification |
|---|---|
| Product Name | Football-Themed Detachable Container House |
| Standard Size | 5950 × 3000 × 2800 mm |
| Floor Area | Approx. 17.85 m² |
| Structure | Cold-formed galvanized steel structure |
| Wall Panel | EPS / Rock Wool / PU Sandwich Panel |
| Wall Thickness | Customizable according to project requirements |
| Roof System | Insulated steel roof system |
| Floor | MGO board or fiber cement board with optional PVC flooring |
| Door | Steel door / security door / aluminum glass door |
| Window | PVC or aluminum sliding window |
| Electrical System | Lighting, switches, sockets and distribution box |
| Installation | Bolted modular assembly |
| Loading Capacity | Up to 17 standard units per 40HQ, depending on configuration |
| Installation Team | Approximately 4 workers |
| Installation Time | Around 3 hours per standard unit under suitable site conditions |
| Wind Resistance | Up to Level 12, depending on final engineering configuration |
| Earthquake Resistance | Up to Level 8, depending on final engineering configuration |
| Number of Floors | Up to 3 floors, subject to structural design and local regulations |
| Exterior Color | Customizable |
| Interior Layout | Customizable |
| Application | Accommodation, office, shop, restaurant, toilet, reception and event facility |
Suitable for large-scale infrastructure, EPC projects, mining, and oil and gas projects, providing on-site personnel with dormitories, offices, canteens, and supporting service spaces.
Worker Dormitories
Can be configured in single-story or multi-story combinations to quickly form centralized accommodation areas; the number of rooms and bed configuration can be designed according to needs.
Project Offices
Can be combined into individual offices, open-plan workspaces, meeting rooms, archives, and reception areas, suitable for construction sites and temporary project headquarters.
Schools and Classrooms
Can be used as temporary classrooms, training centers, teacher offices, laboratories, and student dormitories.
Medical and Emergency Projects
Suitable for temporary clinics, isolation rooms, emergency command centers, and post-disaster resettlement housing, capable of rapid deployment and use.
Commercial Spaces
By changing the exterior wall color, adding glass curtain walls, and customizing the entrance, spaces can be transformed into shops, cafes, ticket offices, and exhibition centers.
Recommend Products
FAQ
In which scenarios are CGCH's products primarily applied?
CGCH modular building products are widely utilized across a diverse range of settings, including commercial retail, dining spaces, cultural tourism and hospitality, engineering camps, emergency support facilities, military research centers, and arts and cultural venues. Whether the project calls for a pop-up shop, a café, or a resort hotel—or even a polar research station or disaster relief housing—we are able to provide customized solutions.
How long does it take to install one standard unit?
The service life varies slightly across different product series:
Detachable and Foldable Container houses: 10–15 years
Expandable Containers: 15–20 years
Space Pods: The main structural components carry a 30-year warranty, and the overall design life exceeds 30 years.
Under conditions of normal use and maintenance, the products are capable of stable, long-term operation.
How is the thermal insulation performance of container homes?
We utilize 50–100mm rock wool, polyurethane (PU), or glass wool sandwich panels, combined with a thermal-break structure, to accommodate environments ranging from extreme cold at -48°C to scorching desert heat at +46°C. The doors and windows come standard with triple-glazed, double-cavity insulated glass, effectively blocking thermal conduction.
What are the typical application scenarios?
We utilize 50–100mm rock wool, polyurethane (PU), or glass wool sandwich panels, combined with a thermal-break structure, to accommodate environments ranging from extreme cold at -48°C to scorching desert heat at +46°C. The doors and windows come standard with triple-glazed, double-cavity insulated glass, effectively blocking thermal conduction.
How long does it take to install a container house?
Installation times vary depending on the product type:
Foldable Container house(Type X): 10 minutes (2 people)
Foldable Container house(Type Z): 15 minutes (3 people + crane)
Detachable Container House: 3 hours (4 people)
Expandable Container House: 10 minutes to expand (4 people)
Space Capsule: Ready for occupancy within 2 hours of arrival
Detailed installation diagrams and video tutorials are provided for all products.
Does CGCH provide overseas installation services?
Yes. For projects valued at over one million, we can dispatch professional technical personnel to the site to supervise the installation. For standard projects, we provide multilingual installation videos, technical drawings, and remote video support to ensure that local workers can complete the installation independently.
Project Cases
Qatar World Cup Fan Village Project
CGCH successfully supplied detachable container houses for the Qatar World Cup Fan Village, providing fast, flexible, and comfortable accommodation solutions for international visitors. Thanks to their modular design, rapid installation, and durable steel structure, the units were deployed efficiently to meet the large-scale accommodation demands of the tournament. This project demonstrated the reliability and versatility of CGCH container housing solutions for major global events.
Russia Yelabuga International Camp Project
CGCH successfully delivered a large-scale Flat Pack Container House project for the Yelabuga International Camp in Russia, providing modern accommodation and support facilities for workers and project personnel. Designed to withstand harsh climate conditions, the modular buildings feature excellent thermal insulation, robust steel structures, and rapid installation capabilities. Through efficient production, transportation, and on-site assembly, CGCH helped the client create a comfortable, durable, and scalable living environment, demonstrating the reliability of our container housing solutions in large international projects.
Philippines Modular Housing Project
Following the powerful earthquakes that struck Turkey in 2023, hundreds of thousands of people were left homeless and in urgent need of emergency housing that could be rapidly deployed, easily transported, and adapted to cold weather conditions. Roads in the disaster zones were severely damaged, making it difficult for heavy machinery to gain access. CGCH supplied 2,000 units of its "Z-type" foldable container housing, featuring extra-thick 75mm wall panels and underfloor heating systems to meet the winter thermal insulation requirements of the affected regions. When folded, ten units can be loaded into a single 40-foot High Cube container, significantly reducing shipping costs. Upon arrival at the site, a team of three workers—assisted by just one small crane—can fully unfold and set up a single unit in as little as 15 minutes, requiring no complex foundation work.
